Armored Steel Plate
Defsys has offerings of Armor Steel Plates of various thicknesses complying with the international standards. The Armored Steel is strong, hard, and tough (does not shatter when struck with a very fast, hard blow). The quenched and tempered protection plates are used in construction of civil and military equipments which are designed to optimize ballistic performance for protection against bullets, projectiles and shaped charges.
Armor Steel Plate are components that are ready to be delivered to the installation site, which is beneficial in terms of schedule as well as transport and storing costs. If needed, the products can also be ordered as shop-primed, furnished with welding bevels, and cut to shape. Pre-marked match marks facilitate installation.
These plates can be used for al type of applications like Vehicle Armoring, Sentry Boxes, Observation Posts, M.B.T.’s etc.
| Thickness | Width | Length |
|---|---|---|
| 4-20 mm | upto 1500 mm | upto 6000 mm |
| 21-100 mm | upto 1800 mm | upto 12000 mm |
Services include Design, Development and Fabrication specific to customer’s requirements.
Armor Steel of Various Thicknesses Against Following Protection Levels is provided by WW Defsys
| Thickness of Armour Plate | Protection against Type of Weapon | Caliber | Type of Bullet | Weight of bullet | Shooting distance | Speed of the bullet V2, 5 (m/s) +/- 10 m/s |
|---|---|---|---|---|---|---|
| 4.5 mm | AK-47 | 7.62 x 39 mm | Full Jacket, pointed, steel core: M43 | 8.0 g | 10 m | 720 m/s |
| 5 mm | INSAS | 5.56 x 45 mm | Full Jacket, pointed, soft core with steel penetrator | 8.5 g | 10 m | 950 m/s |
| 6.2 mm | SLR | 7.62 x 51 mm | Full Jacket, pointed, soft core | 9.5 g | 10 m | 830 m/s |
| 7 mm | SLR Bimetallic | 7.62 x 54 mm | Full Jacket, pointed, hard core | 9.5 g | 10 m | 820 m/s |
| 8 mm - 100 mm | Sniper & Heavy Arms | AP & As per requirement | AP Full Jacketed and Heavy Arms Shell | As per specs | As per specs | As per specs |
Size available: Upto 1500mm Width X 6000mm Length
